Description
The LS321G is a 7075 Aluminum bodied multi- laser aiming device. Includes class IIIA visible green laser, class 2M IR laser, and IR Illuminator coaxially mounted for easy zeroing. Also features an IR Illuminator focus adjustment, quick release picatinny rail mount, remote pressure switch, and IP67 water resistance
FEATURES:
- Coaxial Dual Laser & IR Illuminator
- High/Low Brightness Setting
- Remote Cable Switch
- Quick Release Mount
- IP67 Waterproof
SPECIFICATIONS:
| ELECTRONIC DATA | | MECHANICAL DATA | | LASER DATA |
| Power Source | Battery | | Housing Material | 7075 T6 Aluminum | | Laser & Illuminator Type | Dual Laser & IR Illuminator |
| Battery Type | CR123A | | Surface Finish | MAO | | White LED Output | N/A |
| Battery Life (Hours) | Up to modes | | Adjustment per Click | 0.5 MOA | | IR Illuminator Class | N/A |
| Brightness Setting | Up to modes | | W&E Travel Range | ?50 MOA | | IR Illuminator Output | 0.7mw |
| | | | | | IR Pointer Class | N/A |
| PHYSICAL DATA | | ENVIRONMENT DATA | | IR Pointer Output | 0.1mw(low)/0.7mw(high) |
| Window Size | – | | Storage Temperature | -40?~65? | | Visible Laser Class | IIIA |
| Dimension (in) | 3.6?2.2?1.6 | | Working Temperature | -40?~51? | | Visible Laser Output | 1mw(low)/5mw(high) |
| Weight (oz) | 8.64 | | Submersion | IP67 | | | |
| | | Vibration | 1000G | | |
